Spec description
| DAC section | |
| DAC | TEAC ΔΣ Discrete DAC × 2 |
| Upconvert | 2xFs / 4xFs / 8xFs (maximum 384kHz) |
| Analog audio inputs | |
| Balanced | |
| Connectors | XLR × 1 pair |
| Input impedance | 50kΩ |
| Maximum input level | 5Vrms |
| Unbalanced | |
| Connectors | RCA Pin (gold-plated) × 1 pair |
| Input impedance | 25kΩ |
| Maximum input level | 2.5Vrms |
| Digital audio inputs | |
| USB | |
| Connectors | USB B-type × 1, (USB2.0 compliant) |
| Supported formats | |
| PCM | 16 / 24 / 32bit 44.1k / 48k / 88.2k / 96k / 176.4k / 192k / 352.8k / 384kHz |
| DSD | 2.8M / 5.6M / 11.2M / 22.5MHz |
| Coaxial | |
| Connectors | RCA Pin (god-plated) × 2 pairs |
| Input level | 0.5Vp-p |
| Input impedance | 75Ω |
| Supported formats | |
| PCM | 16 / 24bit 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz |
| DSD | 2.8MHz (176.4kHz/24bit DoP format) |
| Optical | |
| Connectors | Rectangular (TOS) × 2 pairs |
| Input level | –24.0 to –14.5dBm peak |
| Supported formats | |
| PCM | 16 / 24bit 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz |
| DSD | 2.8MHz (176.4kHz/24bit DoP format) |
| ETHERNET | |
| Connector | RJ-45 × 1 (1000Base-T) |
| Supported formats | |
| PCM | 16 / 24 / 32bit 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz / 352.8k / 384kHz (Stereo) |
| DSD | 2.8M / 5.6M / 11.2M / 22.5MHz (Stereo) |
| Supported formats | |
| PCM lossless | FLAC, Apple Lossless (ALAC), WAV, AIFF, MQA |
| DSD lossless | DSF, DSDIFF (DFF), DoP |
| Compressed audio | MP3, AAC (m4a container) |
| USB flash drive | |
| Connectors | USB A-type × 2 (Front × 1, Rear × 1, USB2.0 compliant) |
| Supported file system | FAT32, exFAT and NTFS single partation |
| Supported file format | |
| PCM | 16 / 24 / 32bit 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz / 352.8k / 384kHz (Stereo) |
| DSD | 2.8M / 5.6M / 11.2M / 22.5MHz (Stereo) |
| Supported file formats | |
| PCM lossless | FLAC, Apple Lossless (ALAC), WAV, AIFF, MQA |
| DSD lossless | DSF, DSDIFF (DFF), DoP |
| Compressed audio | MP3, AAC (m4a container) |
| Bluetooth® | |
| Bluetooth® version | 4.2 |
| Output class | Class2 (rrange: 10m) |
| Supported profile | A2DP, AVRCP |
| Supported A2DP codec | LDAC, LHDC, AAC, SBC, Qualcomm®aptX™ audio/HD audio |
| A2DP content protection | SCMS-T |
| Number of saved pairings | Maximum 8 |
| Analog audio outputs | |
| Balanced | |
| Connectors | XLR (gold-plated pins) × 1 pair |
| Output impedance | 220Ω |
| Output level settings | Selectable from Fixed (0dB), Fixed (+6dB), Variable, or Off |
| Maximum output level | 2.0Vrms (1kHz, Full-scale, 10kΩ loaded, FIxed at 0dB) 4.0Vrms (1kHz, Full-scale, 10kΩ loaded, FIxed at +6dB) 12Vrms (1kHz, Full-scale, 10kΩ loaded, Variable) |
| Unbalanced | |
| Connectors | RCA Pin (gold-plated) × 1 pair |
| Output impedance | 180Ω |
| Output level settings | Selectable from Fixed (0dB), Fixed (+6dB), Variable, or Off |
| Maximum output level | 2.0Vrms (1kHz, Full-scale, 10kΩ loaded, FIxed at 0dB) 4.0Vrms (1kHz, Full-scale, 10kΩ laoded, Fixed at +6dB) 6.0Vrms (1kHz, Full-scale, 10kΩ loaded, Variable) |
| Headphone outputs | |
| Balanced | |
| Connector | 4-pin XLR × 1 |
| Pin asign | Pin1: L+, Pin2: L–, Pin3: R+, Pin4: R– |
| Unbalanced | |
| Connector | 6.3mm Stereo jack (gold-plate) × 1 |
| Maximum output power | |
| Balanced | 700mW + 700mW (32Ω loaded) |
| Unbalanced | 500mW + 500mW (32Ω × 1 loaded) |
| Supported impedance | 16 to 600Ω |
| Clock sync input | |
| Connector | BNC (gold-plated) × 1 |
| Input frequency | 10MHz |
| Input impedance | 50Ω |
| Input level | |
| Rectangle wave | Equivalent to TTL |
| Sine wave | 0.5 to 1.0Vrms |
| External control | |
| Trigger Input (12V TRIGGER IN) | |
| Connector | 3.5mm Mono mini jack × 1 |
| Input level | 12V, 1mA |
| Trigger output (12V TRIGGER THRU) | |
| Connector | 3.5mm Mono mini jack × 1 |
| Output level | 12V |
| Maximum current supply | 100mA |
| Audio performance | *Measurement conditions: Input signal: 192kHz/24-bit PCM, Measurement output: RCA, DAC low-pass filter: On |
| Frequency response | 5Hz to 80,000Hz (+1dB/–5dB) |
| Total harmonic distortion | 0.002% |
| S/N ratio | 108dB (A-Weight, 1kHz) |
| Power | |
| AC120V, 60Hz | |
| AC220 - 240V, 50/60Hz | |
| Power consumption | 40W |
| Standby power | 0.4W |
| Overall dimensions | 444 (W) × 111 (H) × 334 (D) mm (including protrusions) |
| Weight | 11.8kg |
| Operating Temperature | ＋5℃ to ＋35℃ |
| Operating Humidity Range | 5% to 85% (no condensation) |
| Storage Temperature Range | –20℃ to ＋55℃ |
| Included accessory | Power cord, Remote control (RC-1330), AAA batteries × 2, Owner's manual, Foot pad x 3 |
