Cassette tape
| Track system | 4-track 2-channel stereo |
| Head construction | recording/playback head × 1, Erase head × 1 |
| Tape type | C-46/C-60/C-90 |
| Tape speed | 4.76cm/sec |
| Motor | DC servo motor× 1 |
| Pitch control | about +/-10% (playback only) |
| Wow and flutter | 0.25% (W.RMS) |
| Frequency response (overall) | |
| Chrome | 50 to 12,000Hz +/-3dB |
| Normal | 50 to 12,000Hz +/-3dB |
| S/N ratio (overall) | 59dB (3%THD level WTD) |
| Winding time | about 120 seconds (C-60 tape) |
| Line input (RCA) | 462mV (50kΩ or higher input impedance) |
| Line output (RCA) | 462mV (50kΩ or higher impedance load) |
CD player
| Pickup | 3-beam semiconductor laser |
| Digital filter | 8x oversampling digital filter |
| Frequency response | 20Hz to 20kHz +/-2dB |
| Total harmonic distortion | 0.02% or less (1kHz) |
| S/N ratio | 87dB or more (IHF-A) |
| Analog output (RCA) | 2.0V |
USB
| Interface | USB 1.1 FULL SPEED (12Mbps) |
| Playback | |
| Format | MP3 |
| Frequency response | 20Hz to 20,000Hz(+/-2dB) |
| S/N ratio | 85dB or less |
| Playback bit rate | 8k to 320k bps |
| Recording | |
| Format | MP3 |
| Frequency response | |
| CD → USB | 20Hz to 15,000Hz(+/-3dB) |
| LINE IN → USB | 100Hz to 15,000Hz(+/-3dB) |
| S/N ratio | 85dB or more |
| Bit rate | 128kbps |
Microphone input
| Connector | 6.3mm(1/4") mono phone jack |
| Nominal input level | 0.78mV (−60dBm) |
| Input impedance | 47kΩ or more |
| Power supply function | None |
Other
| Power | 100V AC, 50/60Hz |
| Europe | AC 230V, 50Hz |
| USA/Canada | AC 120V, 60Hz |
| JAPAN | AC 100V, 50/60Hz |
| Power Consumption | 13W |
| Dimensions | 435(W) × 145(H) × 288(D)mm(including protrusions) |
| Weight (Net) | 4.8kg (10 5/8 lb) |
| Operating temperature | 5 to 35˚C |
| Operating humidity | 5 to 85% (no condensation) |
| Storage temperature | -20 to 55˚C |
| Accessories | Remote control (RC-1329), AAA batteries × 2, Rack RCA audio cables × 2, Owner’s manual(Warranty card), Quick start guide for recording |
