Regular price
€975,00 EUR
Regular price
Sale price
€975,00 EUR
Unit price
per
Tax included.
0 in Stock. Available online!
Couldn't load pickup availability
Spec description
| Amplifier section | |
| Rated output | 25W + 25W (LINE IN, 1kHz, 8Ω, THD 0.03%, JEITA ) 50W + 50W (LINE IN, 1kHz, 4Ω, THD 0.03%, JEITA ) |
| Digital audio inputs | |
| COAXIAL | |
| Connector | RCA × 1 |
| Supported samplign frequency | |
| LPCM | 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz, 16 / 24bit |
| DSD | 2.8MHz (in 176.4kHz/24bit DoP format) |
| OPTICAL | |
| Connector | TOS-link × 1 |
| Supported samplign freqeuncy | |
| LPCM | 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192kHz, 16 / 24bit |
| DSD | 2.8MHz (in 176.4kHz/24bit DoP format) |
| USB | |
| Connector | USB Type-C × 1 (USB2.0 complied) |
| Supported samplign freqeuncy | |
| LPCM | 44.1k / 48k / 88.2k / 96k / 176.4k / 192k / 352.8k / 384kHz, 16 / 24 / 32bit |
| DSD | 2.8M / 5.6M / 11.2MHz |
| HDMI | |
| Connector | HDMI Type-A × 1 |
| Supported formats | ARC/eARC 192kHz, 24bit (PCM) |
| Analog audio inputs | |
| LINE | |
| Connector | RCA × 2 pairs |
| Input impedance | 10kΩ |
| Bluetooth® section | |
| Version | 4.2 |
| Class | Class2 (range: approx. 10m / 33ft.) |
| Supported profile | A2DP, AVRCP |
| Supported codec | LDAC, LHDC, Qualcomm® aptX™ HD audio, Qualcomm® aptX™ audio, AAC, SBC |
| A2DP contents protection | SCMS-T |
| Number of paring memory | Max. 8 dvices |
| Multi-point connection | Max. 2 dvices |
| Speaker output | |
| Connectors | Screw type × 1 pair (compatible with Banana plug) |
| Compatible speaker impedance | 4Ω to 8Ω |
| Headphone output | |
| Connector | 3.5mm 4-pole Stereo mini × 1 |
| Pin assignment | Tip: L+, Ring: R+, Ring: L–, Sleeve: R– |
| Rated output power | 220mW + 220mW (LINE IN, 32Ω, 1kHz, THD 1%, JEITA) |
| THD | 0.006 % (LINE IN, 32Ω, 1kHz, 50mW, JEITA) |
| Power | AC 100 - 240V, 50/60Hz |
| Power consumption | 63W |
| Overall dimensions (W×H×D) | 215 × 61 × 257 mm (including protrusion) |
| Weight | 2.3kg |
| Included accessories | Power cord, Remote control (RC-1337) , AAA batteries × 2, Owner's manual, Warranty |
* RoHS complied
* Design and specifications subject to chnge without notice.
Audio performance
| Frequency response | 2 to 70kHz (LINE IN, –5dB, JEITA) |
| THD | 0.008% (LINE IN, 20Hz to 20kHz, 4Ω, 6.25W, JEITA) 0.004% (LINE IN, 1kHz, 4Ω, 6.25W, JEITA) |
| S/N ratio | 100dB (LINE IN, JEITA) |
