Specifications
| Operating Voltage V-Hz-Ph | 220-240V, 1Ph, 50Hz |
|---|---|
| Operation Type | Ψ / Θ |
| Rated Yield Btu / h | 12000 |
| Cooling Performance Btu / h | 12000(1800-13607) |
| Cooling Efficiency kW | 3.52(0.53-3.99) |
| Thermal Efficiency Btu / h | 13000(3400-14975) |
| Thermal Efficiency kW | 3.81(1.00-4.39) |
| Power Supply Cooling W | 1053(155-1373) |
| Power Supply Heating W | 1038(302-1390) |
| Seasonal Degree of Energy Efficiency (SEER) Cooling | 6.5 |
| Seasonal Rate of Performance (SCOP) Heating (Average) | 4.00 |
| Seasonal Rate of Performance (SCOP) Heating (Warm) | 5.1 |
| Cooling Energy Class | A++ |
| Heating Energy Class (Medium Zone) | A+ |
| Heating Energy Class (Warm Zone) | A+++ |
| Static Pressure, Rated Power (Pa) | 25 |
| Static Pressure, Power Range (Pa) | 0-60 |
| Cooling Operating Current A | 4.75(1.3-6.09) |
| Operating Current Heating A | 4.52(1.48-6.15) |
| Air supply m³ / h (Y / M / H) Indoor | 600/480/300 |
| Indoor Unit Noise Level dB (A) (H / M / H / H) | 34.5/30.5/29/23 |
| Indoor Unit Sound Power dB (A) | 58 |
| Outdoor Unit Sound Power in dB (A) | 62 |
| Internal Temperature Operating Range (Cooling) ℃ | 16-32 |
| Internal Temperature Operating Range (Heating) ℃ | 0-30 |
| Outdoor Temperature Operating Range (Cooling) ℃ | -15~50 |
| Outdoor Temperature Operating Range (Heating) ℃ | -15~24 |
| Indoor Unit Dimensions (H x W x D) mm | 700x450x200 |
| Outdoor Unit Dimensions (H x W x D) mm | 765x303x555 |
| Net Indoor Unit Weight Kg | 17.8 |
| Net Weight of Outdoor Unit Kg | 26.6 |
| Liquid / Gas Piping Diameter mm | 6.35(1/4)/9.52(3/8) |
| Maximum Piping Length m | 25 |
| Maximum Altitude Difference m | 10 |
| Coolant | R32 |
| Wi-Fi function | Optional |
