Marantz PM8006 INTEGRATED AMPLIFIER WITH NEW PHONO-EQ
Marantz PM8006 INTEGRATED AMPLIFIER WITH NEW PHONO-EQ
Regular price
€1.850,00 EUR
Regular price
€0,00 EUR
Sale price
€1.850,00 EUR
Unit price
per
Tax included.
0 in Stock. Available online!
Couldn't load pickup availability
Features
| Channels | 2 |
| Current Feedback Topology | Yes |
| Full balanced circuitry architecture | No |
| Double Mono Power Amp construction | No |
| Phono EQ: Standard / Marantz Musical / Marantz Musical Premium | No / Yes / No |
| Digital in: USB-B / optical / coaxial / USB-A | No / No / No / No |
| Sample Rate digital In | No |
| USB-A: DSD / WAV / FLAC / AIFF / ALAC | No |
| USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 | No |
| USB-B PCM sample rate | No |
| DAC chip | No |
| Asynchronous mode rear USB | No |
| Bit-perfect transmission | No |
| Ground isolator for DAC Mode operation | No |
| Bluetooth / aptX / NFC | No |
| Streaming audio from PC | No |
| Wi-Fi / Wired LAN | No |
| Internet radio | No |
| AirPlay Audio Streaming | No |
| Windows Play to | No |
| vTuner / Spotify* | No |
| DLNA certified | No |
| DSD-Audio network streaming | No |
| Lossy formats: MP3 / WMA / AAC | No |
| Lossless formats: DSD / FLAC192/24 / ALAC96/24 / WAV192/24 / AIFF192/24 | No |
| Gapless Playback | No |
| Remote APP: iDevice / Android | No |
| Analog Mode | No |
| HDAM version | SA3, SA2 |
| Power Transformer: Toroidal / El | Yes / No |
| High Grade Audio Components | Yes |
| Customised Components | Yes |
| Symmetric PCB Layout | Yes |
| Aluminium extrusion heat sink | Yes |
| Copper Plated Chassis | No |
| Tri Tone Control (Bass / Mid / Treble) | Yes |
| Balance / Bass / Treble / Loudness | Yes / Yes / Yes / No |
Others
| Marantz Musical Digital Filtering | No |
| Linear Drive Power Supply | Yes |
| Liniear volume control | Yes |
| BI-AMP and Multichannel option | No |
| Shottky diodes | Yes |
| Input buffer amp (all inputs / CD only) | No / Yes |
| System block shielding: Copper / metal / none | No / No / Yes |
| Double Layer Bottom Plate | triple |
| Low Noise OELD display | No |
| Low noise LCD display | No |
| Source Direct | Yes |
| Power Amp direct | Yes |
| 5mm aluminium top plate | No |
Inputs/Outputs
| Audio Inputs | 6 |
| Digital in: USB-B / optical / coaxial / USB-A | No / No / No / No |
| Phono Input: MM / MC | Yes / No |
| Audio Outputs | 1 |
| Balanced In / Out | No / No |
| Pre-out / Main-in | 1 / No |
| Power Amp Direct IN | Yes |
| Gold Plated Cinch | Yes |
| Speaker A / B | Yes |
| Speaker Terminals | Marantz SPKT-1+ |
| Number of terminals | 4 |
| D-Bus | Yes |
| Floating Control Bus (3.5 mm mono jack x 2) | No |
| Headphone Out | Yes |
| Headphone Gain Control (low / mid / high) | No |
Specifications
| Power Output (8 / 4 Ohm RMS) | 70 W / 100 W |
| Frequency response | 5 Hz-100 kHz |
| Total Harmonic Distortion | 0.02% |
| Damping Factor | 100 |
| Input Sensitivity: MM | 2 mV / 47 kOhm |
| Input Sensitivity: MC | No |
| Signal to Noise Ratio: MM/MC | 87 dB / No |
| Input Sensitivity: High level | 200 mV / 20 kOhm |
| Input Sensitivity: Balanced High level | No |
| Signal to Noise Ratio: High level | 106dB(2V input) |
| Input Sensitivity: Power Amp Direct IN | 1.6V / 15 kOhm |
| Signal to Noise Ratio: Power Amp Direct IN | 125 dB |
General
| Available Colors: Gold / Silver / Black / Silver-Gold | No / No / Yes / Yes |
| Metal Front Panel | Yes |
| Power Consumption in W | 220 |
| Standby Consumption in W | 0.2 |
| Auto Power off | Yes |
| Detachable Power Cable | Yes |
| Remote Control | RC001PMND |
| System Remote Function | Yes |
| Maximum Dimensions (W x D x H) in mm | 440 x 379 x 128 |
| Weight in kg | 12 |
