Regular price
€649,00 EUR
Regular price
€0,00 EUR
Sale price
€649,00 EUR
Unit price
/
per
Sale
Sold out
Tax included.
0 in Stock. Available online!
Couldn't load pickup availability
Features
Channels |
2 |
Current Feedback Topology |
0 |
Phono EQ: Standard |
0 |
Digital In: Optical / Coaxial |
Yes / Yes |
DAC chip |
CS4398 |
HDAM version |
SA3, SA2 |
Toroidal Transformer |
0 |
High Grade Audio Components |
0 |
Customized Components |
0 |
Aluminium extrusion heat sink |
0 |
Balance / Bass / Treble / Loudness |
Yes / Yes / Yes / Yes |
Others
Linear Drive Power Supply |
0 |
Shottky diodes |
0 |
Copper Plated Screws |
0 |
Standby Mode |
0 |
Inputs/Outputs
Audio Inputs |
5 |
Digital In: Optical / Coaxial |
2 / Yes |
Phono Input: MM |
0 |
Audio Outputs |
1 |
Gold Plated Cinch |
0 |
Speaker A / B |
0 |
Speaker Terminals |
Metal (Gold) Screw |
Number of terminals |
4 |
D-Bus |
0 |
Headphone Out |
0 |
Headphone Volume Control |
0 |
Specifications
Power Output (8 / 4 Ohm RMS) |
45 W / 60 W |
Frequency response |
10 Hz-70 kHz |
Total Harmonic Distortion |
0.08% |
Damping Factor |
100 |
Input Sensitivity |
MM 2.2 mV / 47 kOhm |
Signal to Noise Ratio |
MM 83 dB |
Input Sensitivity |
High Level 200 mV / 20 kOhm |
Signal to Noise Ratio |
High Level 102dB (2V input) |
General
Available color: Black |
0 |
Metal Front Panel |
0 |
Power Consumption |
395 W |
Standby Consumption |
0.3 W |
Auto Power off |
0 |
Detachable Power Cable |
0 |
Remote Control |
RC003PMCD |
System Remote Function |
0 |
Maximum Dimensions (W x D x H) |
17.3 x 14.6 x 4.1 |
Weight |
17.2 lbs |
