Regular price
€9.999,00 EUR
Regular price
€0,00 EUR
Sale price
€9.999,00 EUR
Unit price
per
Tax included.
0 in Stock. Available online!
Couldn't load pickup availability
| Channels | 2 |
| Current Feedback Topology |  |
| Full balanced circuitry architecture | |
| Double Mono Power Amp construction | |
| Phono EQ: Standard / Marantz Musical / Marantz Musical Premium |
 / /
|
| Digital in: USB-B / optical / coaxial / USB-A |
/ / /
|
| Sample Rate Digital In | |
| USB-A: DSD / WAV / FLAC / AIFF / ALAC | |
| USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 | |
| USB-B PCM sample rate | |
| DAC chip | |
| Asynchronous mode rear USB | |
| Bit-perfect transmission | |
| Ground isolator for DAC Mode operation | |
| Bluetooth / aptX / NFC | |
| Streaming audio from PC | |
| Wi-Fi / Wired LAN | |
| Internet radio | |
| AirPlay Audio Streaming | |
| Windows Play to | |
| vTuner / Spotify* | |
| DLNA certified | |
| DSD-Audio network streaming | |
| Lossy formats: MP3 / WMA / AAC | |
| Lossless formats: DSD / FLAC192/24 / ALAC96/24 / WAV192/24 / AIFF192/24 | |
| Gapless Playback | |
| Remote APP: iDevice / Android | |
| Analog mode | |
| HDAM version | SA3 |
| Power Transformer: Toroidal / El | SMPS |
| High Grade Audio Components | |
| Customised Components | |
| Symmetric PCB Layout | |
| Aluminium extrusion heat sink |
(Separate) |
| Copper plated chassis | |
| Tri Tone Control (Bass / Mid / Treble) | |
| Balance / Bass / Treble / Loudness |
/ / /
|
| Marantz Musical Digital Filtering | |
| Linear Drive Power Supply |
(pre-amplifier stage) |
| Liniear volume control | |
| BI-AMP and Multichannel option | |
| Shottky diodes | |
| Input buffer amp (all inputs / CD only) |
/
|
| System block shielding: copper / metal / none |
/ /
|
| Double Layer Bottom Plate | |
| Low Noise OELD display | |
| Low noise LCD display | |
| Source Direct | |
| Power Amp direct | |
| 5mm aluminium top plate |
|
| Audio Inputs | 7 |
| Digital in: USB-B / optical / coaxial / USB-A |
/ / /
|
| Phono Input: MM / MC |
/
|
| Audio Outputs | 1 |
| Balanced In / Out | 2 /
|
| Pre-out / Main-in |
/
|
| Power Amp Direct IN | |
| Gold Plated Cinch |
/ CD & Phono nickel-plated |
| Speaker A / B | |
| Speaker Terminals | Marantz SPKT-100+ |
| Number of terminals | 4 |
| D-Bus | |
| Floating Control Bus (3.5 mm mono jack x 2) | |
| Headphone Out | |
| Headphone Gain Control (low / mid / high) | |
| Power Output (8 / 4 Ohm RMS) | 200 W / 400 W |
| Frequency Response | 5 Hz 50kHz |
| Total Harmonic Distortion | 0.01% |
| Damping Factor | 500 |
| Input Sensitivity: MM | 2.6 mV / 47 kohm |
| Input Sensitivity: MC | 280 |
| Input Sensitivity: High level | 400 mV / 20 kohm |
| Input Sensitivity: Balanced High level | 800 mV / 40 kohm |
| Signal to Noise Ratio: High level | 111 dB(2V input/Rated output) |
| Input Sensitivity: Power Amp Direct IN | 1,5 V / 20 kohm |
| Signal to Noise Ratio: Power Amp Direct IN | 113 dB |
| Available colors: Gold / Silver / Black / Silver-Gold |
/ / /
|
| Metal Front Panel | |
| Power Consumption in W | 270 |
| Standby Consumption in W | 0.3 |
| Auto power off | |
| Detachable Power Cable | |
| Remote Control | RC004PMSA |
| System Remote Function | |
| Maximum Dimensions (W x D x H) in mm | 440 x 168 x 453 |
| Weight in kg | 21.5 |
