Features
Network Audio Streaming |
Yes |
Spotify Connect* / Tidal* / Deezer* / others * |
Yes / Yes / Yes / Yes |
AirPlay Audio Streaming |
Yes |
AirPlay 2 Audio Streaming |
Yes |
Internet radio |
tunein |
HEOS Multiroom and Streaming |
Yes |
CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC |
Yes / Yes / No / Yes / Yes / No |
CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data |
No / No / Yes / Yes / No |
Data Disc Compatibility: DSD / WAV / ALAC |
No / No / No |
USB input |
No / No / No |
DAC operation mode: USB / Coax / Optical |
Yes / Yes / Yes |
Asynchronous mode rear USB |
Yes / Yes / Yes |
Bit-perfect transmission |
Yes |
USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 / DSD11.2 |
Yes / Yes / Yes |
Signal isolator for DAC Mode operation |
Yes |
Jitter reducer |
Yes |
HDAM version |
HDAM+HDAM SA2 |
Power Transformer |
Yes / No |
High Grade Audio Components |
Yes |
Customised Components |
Yes |
Symmetric circuit layout |
Yes |
Copper Plated Chassis |
No |
Extra metal plate for chassis strengthing |
Yes (1.5mm) |
Digital out off / Audio EX Mode |
Yes / No |
Headphone: Standard / Buffer / Current feedback |
No / No / Yes (HDAM SA2) |
Network
Wi-Fi / Wired LAN |
2.4GHz, 5GHz / Yes |
Wi-Fi on / off mode |
Yes |
Bluetooth on / off mode |
Yes |
Lossy formats: MP3 / WMA / AAC |
Yes / Yes / Yes |
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 96/24 |
Yes / Yes / Yes / Yes |
Gapless Playback |
Yes (FLAC, WAV, DSD) |
Remote APP: iDevice / Android |
Yes / Yes |
App control AMP/CD via Network Player |
Yes |
Others
Selectable filter: CD / SA-CD / DAC-Mode |
Yes/ No / Yes(PCM Only) |
Marantz Musical Mastering |
No |
Marantz Musical Mastering Stream |
No |
Marantz Musical Mastering Conversion |
No |
Separated rectifier circuit for analog and digital circuitry |
Yes |
Display: Dimmer / Off |
Yes / Yes |
Playback
Program Play (CD / SA-CD) |
25 / No |
Repeat |
Yes |
Random Play |
Yes |
Inputs/Outputs
Analogue Out (Cinch) |
Yes |
Variable Out (Cinch) |
Yes |
Balanced Out |
No |
Digital Optical In / Out |
2 / 1 |
Digital Coaxial In / Out |
1 / 1 |
Sample Rate digital In |
192 kHz / 24-bit |
Gold Plated Cinch |
Yes |
USB Audio (Front) / Made for iPod / Made for iPhone® |
Yes |
USB type B input for PC (back) |
Yes |
Sample Rate USB type B In |
up to DSD11.2 |
D-Bus |
Yes |
Headphone Out |
Yes |
Headphone Volume Control |
Yes |
Ethernet port |
Yes |
IP control |
Yes |
Flasher IN / OUT |
Yes |
RS232 |
Yes |
Specifications
Mechanism |
JTL-101Y |
D/A Conversion |
ESS Hyper Stream |
DAC IC |
ES9016 |
Digital Filter |
ES9016 |
Noise Shaper |
ES9016 |
Low Pass Filter stage |
HDAM |
Output Buffer |
HDAM SA2 |
Headphone amp |
HDAM SA2 |
Frequency Response (Cust.) |
No |
Dynamic Range (SA) |
No |
Signal to Noise Ratio (SA) |
No |
Total Harmonic Distortion (SA) |
No |
Channel Separation (SA) |
No |
Frequency Response |
2 Hz-20 kHz |
Dynamic Range |
100 dB |
Signal to Noise Ratio |
110 dB |
Total Harmonic Distortion |
0.00002 |
Channel separation |
105 dB |
General
Available Colors: Gold / Silver / Black / Silver-Gold |
No / No / Yes / Yes |
Metal Front Panel |
Yes |
Remote Control |
RC001PMND |
Power Consumption in W |
42 |
Standby Consumption in W |
0.3 |
Auto Power off |
Yes |
Detachable Power Cable |
Yes |
Maximum Dimensions (W x D x H) in mm |
440 x 341 x 106 |
Weight in kg |
8 |
