Combining decades of innovative, award-winning disc-player design with refined, modern mastery, the CD 70 is engineered for the contemporary music collector. Featuring expertly crafted components, a high-performance DAC, CD 70 ensures your favorite Compact Discs always sound exceptional. Whether it’s rediscovering a classic from your collection or enjoying a brand-new release—or even listening in high-resolution via USB-A playback—you’ll hear every instrument, note, and nuance with uncompromising clarity and musical warmth.
Upgraded high-performance DAC
Marantz HDAM-SA2 circuitry
USB-A high-resolution playback
Supports FLAC, ALAC and DSD
Dedicated headphone amplifier
Timeless Marantz industrial design
Features
CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AACYes / Yes / No / Yes / Yes / No
CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta dataNo / No / Yes / Yes / Yes
Data Disc Compatibility: DSD / WAV / ALACNo / No / No
DAC Master Clock DesignYes
HDAM versionHDAM / HDAM SA2
Power Transformer: Toroidal / ElYes / No
High Grade Audio ComponentsYes
Customised ComponentsYes
Symmetric circuit layoutYes
Extra metal plate for chassis strengtheningYes
Digital out off / Audio EX ModeYes / No
Headphone: Standard / Buffer / Current feedbackNo / Yes (HDAM-SA2) / No
Others
Selectable filter: CD / SA-CD / DAC-ModeYes / No / No
Separated rectifier circuit for analogue and digital circuitryYes
Display: Dimmer / OffYes / Yes
VFD displayYes
Playback
Program Play (CD / SA-CD)25
RepeatYes
Random PlayYes
Inputs Outputs
Analogue Out (Cinch)2ch
Digital Optical In / Out0 / 1
Digital Coaxial In / Out0 / 1
Gold Plated CinchYes
USB Audio (Front) / Made for iPod / Made for iPhone®Yes / No / No
USB-A: FLAC / WAV / AIFF / ALAC / DSDYes
D-BusYes
Headphone OutYes
Headphone Volume ControlYes
Specifications
MechanismYes
D/A ConversionYes
DAC IC, Digital Filter, Noise ShaperYes
Low Pass Filter stage
Output Buffer
Headphone amp
Frequency Response2 Hz - 20 kHz
Dynamic Range100 dB
Signal to Noise Ratio110 dB
Total Harmonic Distortion0.0016%
Channel separation98 dB
General
Available ColorsBlack / Silver-Gold
Metal Front PanelYes
Remote ControlRC006PMCD
Power Consumption in W32
Standby Consumption in W0.3
Auto Power offYes
Detachable Power CableYes
Maximum Dimensions (W x D x H) in inches17.40 × 13.82 × 4.29
Weight in lbs.14.3
Carton Maximum Dimensions (W x D x H) in inches20.55 × 18.46 × 7.48
