Regular price
€549,00 EUR
Regular price
€0,00 EUR
Sale price
€549,00 EUR
Unit price
/
per
Sale
Sold out
Tax included.
0 in Stock. Available online!
Couldn't load pickup availability
Features
| CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC |
Yes / Yes / No / Yes / Yes / No |
| CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data |
No / No / Yes / Yes / Yes |
| Data Disc Compatibility: DSD / WAV / ALAC |
No / No / No |
| DAC operation mode: USB / Coax / Optical |
No / No / No |
| Asynchronous mode rear USB |
No |
| Bit-perfect transmission |
No |
| USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 |
No |
| Signal isolator for DAC Mode operation |
No |
| HDAM version |
HDAM+HDAM SA2 |
| Power Transformer: Toroidal / El |
No / Yes |
| High Grade Audio Components |
Yes |
| Customised Components |
Yes |
| Symmetric circuit layout |
Yes |
| Copper Plated Chassis |
No |
| Extra metal plate for chassis strengthing |
Yes |
| Digital out off / Audio EX Mode |
Yes / No |
| Headphone: Standard / Buffer / Current feedback |
No / Yes (HDAM-SA2) / No |
Others
| Selectable filter: CD / SA-CD / DAC-Mode |
Yes / No / No |
| Marantz Musical Mastering |
Yes |
| Marantz Musical Mastering Stream |
No |
| Marantz Musical Mastering Conversion |
No |
| Separated rectifier circuit for analog and digital circuitry |
Yes |
| Display: Dimmer / Off |
Yes / Yes |
| Low noise LCD display |
No |
| 5mm Aluminum top cover |
No |
Playback
| Program Play (CD / SA-CD) |
25 |
| Repeat |
Yes |
| Random Play |
Yes |
| Start Sound Mode for SA-CD |
No |
Inputs/Outputs
| Analogue Out (Cinch) |
2ch |
| Balanced Out |
No |
| Digital Optical In / Out |
No / 1 |
| Digital Coaxial In / Out |
No / 1 |
| Sample Rate digital In |
No |
| Gold Plated Cinch |
Yes |
| USB Audio (Front) / Made for iPod / Made for iPhone® |
Yes / No / No |
| USB-A: FLAC / WAV / AIFF / ALAC / DSD |
Yes |
| USB type B input for PC (rear) |
No |
| Asynchronous mode rear USB |
No |
| Sample Rate USB type B In |
No |
| USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 |
No |
| D-Bus |
Yes |
| Headphone Out |
Yes |
| Headphone Volume Control |
Yes |
Specifications
| Mechanism |
No |
| D/A Conversion |
No |
| DAC IC |
No |
| Digital Filter |
No |
| Noise Shaper |
No |
| Low Pass Filter stage |
No |
| Output Buffer |
No |
| Headphone amp |
No |
| Frequency Response (Cust.) |
No |
| Dynamic Range (SA) |
No |
| Signal to Noise Ratio (SA) |
No |
| Total Harmonic Distortion (SA) |
No |
| Channel Separation (SA) |
No |
| Frequency Response |
2 Hz - 20 kHz |
| Dynamic Range |
100 dB |
| Signal to Noise Ratio |
110 dB |
| Total Harmonic Distortion |
0.002% |
| Channel separation |
98 dB |
General
| Available Colors: Gold / Silver / Black / Silver-Gold |
No / No / Yes / Yes |
| Metal Front Panel |
Yes |
| Remote Control |
RC004PMCD |
| Power Consumption in W |
32 |
| Standby Consumption in W |
0.3 |
| Auto Power off |
Yes |
| Detachable Power Cable |
Yes |
| Maximum Dimensions (W x D x H) in inches |
17.3 x 13.3 x 4.1 |
| Weight in lbs. |
14.3 |
| Carton Maximum Dimensions (W x D x H) in inches |
20.3 x 18.4 x 7.4 |
| Carton Weight (inc. product) in lbs |
19.4 |
