Regular price
€3.260,00 EUR
Regular price
Sale price
€3.260,00 EUR
Unit price
per
Tax included.
0 in Stock. Available online!
Couldn't load pickup availability
Specification table for FTXZ-N
| FTXZ25NV1B | FTXZ35NV1B | FTXZ50NV1B | |||||
|---|---|---|---|---|---|---|---|
| Sound pressure level | Heating | Highness | dBA | 39 | 42 | 44 | |
| Silent mode | dBA | 19 | 19 | 24 | |||
| Low | dBA | 28 | 29 | 31 | |||
| Cooling | Silent mode | dBA | 19 | 19 | 23 | ||
| Low | dBA | 26 | 27 | 30 | |||
| Highness | dBA | 38 | 42 | 47 | |||
| Name | dBA | 35 | 36 | 38 | |||
| Cooling | Name | dBA | 33 | 35 | 38 | ||
| Standard accessories | Photocatalytic cleaning filter with deodorant action | 1 | 1 | 1 | |||
| Wireless remote control | 1 | 1 | 1 | ||||
| Dry type batteries | 2 | 2 | 2 | ||||
| Remote control socket | 1 | 1 | 1 | ||||
| Indoor unit fixing screws | 3 | 3 | 3 | ||||
| Support plate | 1 | 1 | 1 | ||||
| Controls | Infrared remote control | ARC477A1 | ARC477A1 | ARC477A1 | |||
| Piping connections | Liquid | EX. DIAM. | mm | 6.35 | 6.35 | 6.35 | |
| Gas | EX. DIAM. | mm | 9.5 | 9.5 | 9.5 | ||
| Input power | Cooling | Name | kW | 0.030 | 0.030 | 0.030 | |
| Heating | Name | kW | 0.030 | 0.030 | 0.030 | ||
| Sound power level | Cooling | dBA | 54 | 57 | 60 | ||
| Heating | dBA | 56 | 57 | 59 | |||
| Dimensions | Unit | Width | mm | 798 | 798 | 798 | |
| Depth | mm | 372 | 372 | 372 | |||
| Height | mm | 295 | 295 | 295 | |||
| Casing | Colour | White | White | White | |||
| Weight | Unit | kg | 15 | 15 | 15 | ||
| Fan | Airflow speed | Heating | Highness | m³/min | 11.7 | 13.3 | 14.4 |
| Low | m³/min | 6.7 | 6.9 | 7.7 | |||
| Silent mode | m³/min | 4.8 | 4.8 | 5.9 | |||
| Cooling | Low | m³/min | 5.3 | 5.6 | 6.6 | ||
| Highness | m³/min | 10.7 | 12.1 | 15.0 | |||
| Silent mode | m³/min | 4.0 | 4.0 | 4.6 | |||
| Name | m³/min | 8.6 | 9.2 | 10.7 | |||
| Cooling | Name | m³/min | 7.5 | 8.4 | 9.2 | ||
| Power supply | Phase | 1~ | 1~ | 1~ | |||
| Frequency | Hz | 50 | 50 | 50 | |||
| Name | V1 | V1 | V1 | ||||
| Trend | V | 220-240 | 220-240 | 220-240 | |||
| Notes | (1) - 220V | (1) - 220V | (1) - 220V | ||||
| (2) - 230V | (2) - 230V | (2) - 230V | |||||
| (3) - 240V | (3) - 240V | (3) - 240V | |||||
| (4) - Front side of heat exchanger | (4) - Front side of heat exchanger | (4) - Front side of heat exchanger | |||||
| (5) - Back side of heat exchanger | (5) - Back side of heat exchanger | (5) - Back side of heat exchanger | |||||
