Bowers & Wilkins CCM 632 In-Ceiling Speaker

Specifications

• Description: 2-way in-ceiling system
• Drive Units:
  • 1x ø25mm (1in) Nautilus™ swirl loaded aluminum dome tweeter
  • 1x ø150mm (6in) blue aramid fiber cone bass/midrange
• Frequency Range (-6dB): 45Hz – 50kHz
• Recommended Amp Power: 25 – 150w
• Sensitivity SPL (2.83V, 1m): 88dB
• Impedance Nominal (min): 8 ohms (4.5 ohms)

Approximate Dimensions

• Frame Dimensions
  • Frame Diameter: 9.5 "
  • Depth Behind Surface: 5.2 "
• Cut-out Dimensions
  • Cut-out diameter: 8 "
  • Protrusion: 0.2 "
• Pre-mount Kit: C6
• Recommended Back Box: 6C

Approximate Weight

• Shipping: 3kg

Warranty Information

• Manufacturer Warranty (authorized online retailer): 1 Year Parts And Labor
